Complete 8-Camera 4K AcuSense CCTV Security System

Protect your home, business, retail premises, warehouse or commercial property with this complete HiLook 8-camera 8MP 4K CCTV system. The kit combines 8 × HiLook IPC-T381H-MU 8MP AcuSense Smart Hybrid Light turret cameras with an 8-channel HiLook NVR-108MH-C/8P PoE NVR.

Each IPC-T381H-MU delivers detailed 8MP 4K resolution, AI-powered human and vehicle classification, 120dB True WDR, Smart Hybrid Light illumination and built-in dual-microphone audio. The included PoE NVR provides a central recording and management platform while simplifying camera connectivity through its integrated PoE ports.

Key Features

• 8 × HiLook IPC-T381H-MU 8MP 4K AcuSense turret cameras
• 8-channel HiLook NVR-108MH-C/8P PoE NVR
• 8MP resolution — 3840 × 2160
• AcuSense AI with human and vehicle classification
• Smart Hybrid Light with IR and white-light illumination
• Up to 30m night illumination
• 120dB True WDR for challenging lighting conditions
• Built-in arrayed dual microphone on each camera
• Line crossing and intrusion detection
• H.265+ video compression
• microSD card support up to 512GB per camera
• IEEE 802.3af PoE cameras
• IP67 weather-resistant camera housing
• ONVIF compatibility
• 8-channel simultaneous playback
• Up to 8MP recording support on the NVR
• HDMI output up to 4K
• 3-year warranty

Camera Configuration

Camera count: 8
NVR channels: 8
Available NVR channels: 0 — all 8 channels are used by the included cameras.

8 × HiLook IPC-T381H-MU 8MP 4K AcuSense Turret Cameras

The HiLook IPC-T381H-MU is an 8MP 4K AcuSense turret camera designed for reliable surveillance in residential and commercial environments.

With 3840 × 2160 resolution, the camera provides high-detail footage for monitoring entrances, driveways, retail areas, offices, warehouses and other important locations.

Its deep-learning-based human and vehicle classification helps distinguish relevant movement from general motion, while line crossing and intrusion detection provide additional perimeter protection.

Smart Hybrid Light

The IPC-T381H-MU uses Smart Hybrid Light, combining IR and white-light illumination with a range of up to 30 metres.

This provides flexible night-time illumination while allowing the camera to use supplemental visible lighting when supported conditions require it.

Clear Images in Difficult Lighting

With 120dB True WDR, the camera is designed to maintain useful image detail in scenes containing both bright and dark areas, such as entrances with strong outdoor light or areas exposed to backlighting.

Built-In Audio

Each camera includes an arrayed dual microphone, providing built-in audio capture without requiring a separate microphone for the camera.

AI & Perimeter Protection

The camera supports:

• Human classification
• Vehicle classification
• Line crossing detection
• Intrusion detection
• AcuSense intelligent detection

IPC-T381H-MU Technical Specifications

HiLook NVR-108MH-C/8P 8-Channel PoE NVR

The included HiLook NVR-108MH-C/8P provides centralised recording, playback and management for the eight included IP cameras.

With support for cameras up to 8MP / 4K, the NVR is well suited to this high-resolution surveillance configuration.

Its integrated 8-port PoE interface allows the compatible cameras to connect directly to the recorder using Ethernet, reducing the need for a separate PoE switch.

NVR Key Features

• 8-channel IP video input
• Supports up to 8MP / 4K camera resolution
• 80Mbps incoming bandwidth
• 80Mbps outgoing bandwidth
• H.265+ / H.265 / H.264+ / H.264 compression
• Up to 8-channel synchronous playback
• 1-channel 8MP decoding at 30fps
• Up to 5-channel 1080p decoding at 30fps
• 8 × RJ45 10/100Mbps PoE ports
• IEEE 802.3af/at PoE support
• Total PoE budget up to 75W
• 1 × Gigabit network interface
• 1 × SATA HDD bay
• Supports up to 8TB HDD capacity
• HDMI output up to 4K
• VGA output up to 1080p
• 2 × USB 2.0 ports
• Hik-Connect, iVMS-4200 and HiLookVision support
• ONVIF-compatible
• Camera-side VCA support
• 3-year warranty

NVR-108MH-C/8P Technical Specifications

What’s Included

• 8 × HiLook IPC-T381H-MU 8MP 4K AcuSense Turret Cameras
• 1 × HiLook NVR-108MH-C/8P 8-Channel PoE NVR

HDD Not Included

A hard drive is not included in this kit unless specifically stated otherwise. The NVR features 1 × SATA interface and supports up to 8TB HDD capacity.

Channel Configuration

This kit uses all 8 available NVR channels and PoE ports with the included eight cameras. No spare NVR channels are available within this configuration.

The NVR has a maximum total PoE budget of 75W. The supplied cameras should be operated within the NVR's specified PoE capacity.

Ideal Applications

This 8-camera 4K CCTV system is suitable for:

• Homes and residential properties
• Driveways and entrances
• Retail stores and shops
• Offices
• Warehouses
• Workshops
• Commercial buildings
• Small business premises
• Perimeter monitoring
• Car parks and access areas

Why Choose This HiLook 8-Camera Kit?

This configuration combines 8MP 4K image quality, AcuSense AI detection, Smart Hybrid Light, built-in audio and 120dB True WDR with an integrated 8-channel PoE NVR.

It provides a straightforward solution for customers looking for eight-camera coverage with high-resolution recording and intelligent detection, without adding unnecessary components to the system.

Warranty

3-Year Warranty on the supplied HiLook cameras and NVR, as specified for these products.
