Complete 8-Camera 4K CCTV Security System with AI Detection & Active Deterrence

Protect your home or business with this HiLook 8-camera 8MP 4K CCTV security system, combining six IPC-T381H-MU AcuSense turret cameras and two IPC-T289-MU/SL Colour Deterrence turret cameras with a HiLook NVR-108MH-C/8P 8-channel PoE NVR.

The six IPC-T381H-MU 8MP cameras provide detailed 4K surveillance, AcuSense human and vehicle classification, Smart Hybrid Light, 120dB True WDR and built-in dual-microphone audio.

The two IPC-T289-MU/SL Colour Deterrence cameras add active audio deterrence, with a built-in speaker rated up to 110dB, dual microphones, Smart Hybrid Light and intelligent detection. These cameras can be positioned at priority areas, such as entrances, driveways or other locations where an audible warning feature is desirable.

The included 8-channel PoE NVR provides centralised recording, playback and management for all eight cameras. With all eight NVR channels in use, this configuration delivers a complete eight-camera surveillance solution.

Key Features

• 6 × HiLook IPC-T381H-MU 8MP 4K AcuSense turret cameras
• 2 × HiLook IPC-T289-MU/SL 8MP 4K Colour Deterrence turret cameras
• 1 × HiLook NVR-108MH-C/8P 8-channel PoE NVR
• 8MP Ultra HD resolution — 3840 × 2160
• AI-powered human and vehicle classification
• Smart Hybrid Light with IR and white-light illumination
• Up to 30m illumination range
• 120dB True WDR
• Built-in dual microphones on all eight cameras
• 110dB speaker and active audio deterrence on the two IPC-T289-MU/SL cameras
• Line crossing and intrusion detection
• H.265+ video compression
• microSD storage support on both camera models
• PoE / PoE+ connectivity
• IP67 weather-resistant metal camera housings
• ONVIF compatibility
• 8-channel synchronous playback
• HDMI output up to 4K
• 3-year warranty

Camera Configuration

Total cameras: 8
NVR channels: 8
Channels used: 8

6 × HiLook IPC-T381H-MU 8MP 4K AcuSense Turret Cameras

The HiLook IPC-T381H-MU is an 8MP 4K turret camera designed for high-detail surveillance in residential and commercial environments.

Its 1/2.8-inch Progressive Scan CMOS sensor captures video at 3840 × 2160 resolution, providing detailed footage for monitoring entrances, driveways, retail areas, offices, warehouses and other important locations.

AcuSense AI Detection

Deep-learning technology supports human and vehicle classification to help distinguish relevant movement from general activity.

The camera also supports line crossing and intrusion detection for monitoring defined areas and perimeter activity.

Smart Hybrid Light

Smart Hybrid Light combines infrared and white-light illumination with a range of up to 30 metres. This provides flexible night-time monitoring, with supplemental visible lighting available under supported conditions.

120dB True WDR & Built-In Audio

120dB True WDR helps maintain image detail in challenging lighting conditions, including scenes with strong backlighting. The built-in arrayed dual microphone provides audio capture without requiring a separate microphone for each camera.

IPC-T381H-MU Specifications

2 × HiLook IPC-T289-MU/SL 8MP 4K Colour Deterrence Cameras

The HiLook IPC-T289-MU/SL combines 8MP 4K imaging with intelligent detection and active deterrence features. These cameras are well suited to priority monitoring locations where audible warnings and additional visible lighting may be beneficial.

Smart Hybrid Light

The camera combines IR and white-light illumination with a range of up to 30 metres. White-light illumination can provide additional visible lighting under supported security-event conditions, helping produce colour footage when additional lighting is activated.

Active Audio Deterrence

Each IPC-T289-MU/SL includes a built-in speaker rated up to 110dB and an arrayed dual microphone. It supports audible warnings and customisable audio messages or clips.

Intelligent Detection

The camera supports human and vehicle classification, line crossing and intrusion detection. These functions help identify relevant activity in monitored areas.

IPC-T289-MU/SL Specifications

HiLook NVR-108MH-C/8P 8-Channel PoE NVR

The included HiLook NVR-108MH-C/8P manages recording and playback for all eight cameras. It supports IP camera resolutions up to 8MP / 4K and includes eight PoE ports for direct connection to compatible cameras.

NVR Key Features

• 8-channel IP video input
• Supports up to 8MP / 4K cameras
• 80Mbps incoming bandwidth
• 80Mbps outgoing bandwidth
• H.265+ / H.265 / H.264+ / H.264 compression
• Up to 8-channel synchronous playback
• 8 × RJ45 10/100Mbps PoE ports
• IEEE 802.3af/at PoE support
• Total PoE budget up to 75W
• 1 × Gigabit network interface
• 1 × SATA HDD bay
• Supports up to 8TB HDD capacity
• HDMI output up to 4K
• VGA output up to 1920 × 1080
• 2 × USB 2.0 ports
• Hik-Connect, iVMS-4200 and HiLookVision support
• ONVIF-compatible
• Camera-side VCA support
• 3-year warranty

NVR-108MH-C/8P Specifications

What’s Included

• 6 × HiLook IPC-T381H-MU 8MP 4K AcuSense Turret Cameras
• 2 × HiLook IPC-T289-MU/SL 8MP 4K Colour Deterrence Turret Cameras
• 1 × HiLook NVR-108MH-C/8P 8-Channel PoE NVR

HDD Not Included

A hard drive is not included unless specifically stated otherwise. The NVR has one SATA interface and supports up to 8TB HDD capacity.

NVR Channel & PoE Configuration

All 8 NVR channels and PoE ports are used by the included cameras. No spare NVR channels remain in this configuration.

The NVR has a maximum total PoE budget of 75W. The connected cameras must operate within the NVR's specified power capacity.

Ideal Applications

• Homes and residential properties
• Driveways and entrances
• Retail shops and stores
• Offices and commercial premises
• Warehouses and workshops
• Building perimeters
• Car parks and access areas
• Locations requiring active audio deterrence

Why Choose This HiLook CCTV Kit?

This mixed-camera kit combines six AcuSense 4K cameras for general high-resolution surveillance with two Colour Deterrence cameras for locations where audible warnings and additional visible lighting are useful.

All eight cameras provide 8MP resolution, Smart Hybrid Light, human and vehicle classification and 120dB True WDR. The two IPC-T289-MU/SL cameras add built-in speakers rated up to 110dB for active audio deterrence.

The included 8-channel PoE NVR provides centralised recording and management for the complete system.

Warranty

3-Year Warranty on the supplied HiLook cameras and NVR, as specified for these products.
