HiLook 6-Camera CCTV Security System with 180° Panoramic Coverage
Protect your home or business with this HiLook 6-camera CCTV security system, combining five HiLook IPC-T361H-MU 6MP AcuSense turret cameras with one IPC-T289PH-MU/SL 8MP 180° panoramic Active Deterrence camera and an 8-channel network video recorder (NVR).
The five 6MP cameras provide detailed surveillance for individual areas around your property, while the 8MP panoramic camera captures an ultra-wide 180° horizontal view. This combination is suitable for monitoring entrances, driveways, shopfronts, car parks and other areas where broad coverage is useful.
With human and vehicle classification, infrared and white-light illumination on the panoramic camera, built-in audio and active deterrence features, this system combines everyday surveillance with additional monitoring and warning capabilities.
Key Features
- 6-camera CCTV configuration: Five 6MP AcuSense cameras and one 8MP panoramic camera.
- 6MP high-resolution surveillance: IPC-T361H-MU cameras capture 3200 × 1800 video.
- 180° panoramic coverage: The IPC-T289PH-MU/SL uses a dual-lens stitched design to capture a 4256 × 1888 panoramic image.
- AcuSense AI detection: The IPC-T361H-MU cameras support human and vehicle classification.
- Smart Hybrid Light: The panoramic camera combines infrared and white-light illumination up to 30 metres.
- Active Deterrence: The panoramic camera features a built-in strobe light and audible warning capabilities.
- Built-in audio: All included cameras have built-in microphones; the panoramic model also has a speaker supporting two-way audio.
- 120dB True WDR: Helps manage scenes with bright and dark areas.
- H.265+ compression: Helps reduce storage and bandwidth requirements.
- Outdoor protection: Both camera models feature IP67-rated protection.
- 8-channel NVR: Supports the six included cameras, with two channels available for compatible expansion.
Camera Configuration
| Component | Quantity | Model |
|---|---|---|
| 6MP AcuSense turret camera | 5 | HiLook IPC-T361H-MU |
| 8MP 180° panoramic Active Deterrence camera | 1 | HiLook IPC-T289PH-MU/SL |
| Network video recorder | 1 | 8-channel NVR |
HiLook IPC-T361H-MU 6MP AcuSense Turret Cameras – 5 Units
The five IPC-T361H-MU cameras provide detailed monitoring of selected areas around your property. Their 6MP resolution captures 3200 × 1800 video, while AcuSense human and vehicle classification helps distinguish relevant movement from other activity.
Key Features
- 6MP resolution – 3200 × 1800
- AcuSense human and vehicle classification
- Line-crossing and intrusion detection
- 120dB True WDR
- IR night vision up to 30 metres
- Built-in arrayed dual microphone
- H.265+ video compression
- microSD card support up to 512GB
- PoE connectivity
- IP67 weather protection
- ONVIF compatibility
IPC-T361H-MU Technical Specifications
| Specification | Details |
|---|---|
| Model | HiLook IPC-T361H-MU |
| Camera Type | Fixed turret network camera |
| Resolution | 6MP – 3200 × 1800 |
| Image Sensor | 1/2.4-inch Progressive Scan CMOS |
| Lens Options | 2.8mm or 4mm fixed focal lens |
| Aperture | F1.6 |
| Wide Dynamic Range | 120dB True WDR |
| Night Vision | IR illumination up to 30m |
| AI Detection | Human and vehicle classification |
| Smart Detection | Line crossing and intrusion |
| Audio | Built-in arrayed dual microphone |
| Storage | microSD/microSDHC/microSDXC up to 512GB; NAS; ANR |
| Compression | H.265, H.264, H.265+, H.264+, MJPEG |
| PoE | IEEE 802.3af, Class 3 |
| Power Consumption | Up to 9.5W via PoE |
| Network | 10/100Mbps Ethernet |
| Protection | IP67 |
| Material | Metal |
| Dimensions | Ø127.3 × 96.3mm |
| Weight | Approx. 515g |
| NVR Compatibility | ONVIF Profile S and G; ISAPI |
| Viewing Platforms | HiLook/Hikvision NVR, Hik-Connect, iVMS-4200, Hik-Central |
| Warranty | 3 years |
HiLook IPC-T289PH-MU/SL 8MP 180° Panoramic Camera – 1 Unit
The IPC-T289PH-MU/SL is designed for areas that benefit from an ultra-wide field of view. Its dual 2mm lens configuration combines images into a panoramic view with a 180° horizontal field of view, helping monitor a broad area from a single camera position.
Smart Hybrid Light combines infrared and white-light illumination, while person and vehicle detection helps identify relevant activity. The built-in speaker and strobe light provide additional deterrence functions when configured for supported events.
Key Features
- 8MP panoramic resolution – 4256 × 1888
- 180° horizontal field of view
- Dual 2mm fixed lenses with stitched panoramic imaging
- Person and vehicle detection
- Smart Hybrid Light with IR and white-light illumination up to 30m
- Active Deterrence with strobe light and audible warning
- Built-in microphone and speaker
- Two-way audio support
- 120dB WDR
- microSD storage up to 512GB
- H.265+ video compression
- PoE support
- IP67 weather protection
- Hik-Connect and ONVIF support
IPC-T289PH-MU/SL Technical Specifications
| Specification | Details |
|---|---|
| Model | HiLook IPC-T289PH-MU/SL |
| Camera Type | Panoramic fixed turret IP camera |
| Resolution | 8MP – 4256 × 1888 |
| Image Sensor | 1/2.4-inch Progressive Scan CMOS |
| Field of View | 180° horizontal |
| Lens | Dual 2mm fixed focal lenses |
| Aperture | F1.6 |
| Night Illumination | Infrared and white light |
| Illumination Range | Up to 30m |
| Smart Hybrid Light | Supported |
| Wide Dynamic Range | 120dB |
| AI Detection | Person and vehicle detection |
| Smart Detection | Motion detection |
| Audio | Built-in microphone and speaker |
| Speaker Output | Up to 97dB |
| Two-Way Audio | Supported |
| Active Deterrence | Strobe light and audible warning |
| Storage | microSD/microSDHC/microSDXC up to 512GB |
| Compression | H.265+, H.265, H.264+, H.264 |
| Network Interface | RJ45 10/100Mbps |
| PoE | IEEE 802.3af, Class 3 |
| Power | 12V DC or PoE |
| Weatherproof Rating | IP67 |
| Material | Metal base with plastic cover |
| Dimensions | Ø138.3 × 115.4mm |
| Weight | Approx. 790g |
| Operating Temperature | -30°C to 60°C |
| Warranty | 3 years |
8-Channel Network Video Recorder
The included 8-channel NVR provides centralised recording and management for the six cameras in this system.
With six channels used, two channels remain available for compatible additional IP cameras. Expansion depends on the exact NVR model, camera compatibility and available PoE power budget.
The NVR model has not been specified, so its detailed recording, networking, PoE and storage specifications should be confirmed before publishing.
What’s Included
- 5 × HiLook IPC-T361H-MU 6MP AcuSense turret cameras
- 1 × HiLook IPC-T289PH-MU/SL 8MP 180° panoramic camera
- 1 × 8-channel network video recorder
Hard drive: Not specified as included. Confirm the selected NVR configuration and storage requirements before purchase.
Ideal Applications
This mixed-camera CCTV system may suit:
- Residential driveways and front entrances
- Retail shops and shopfronts
- Offices and commercial buildings
- Car parks and building access points
- Warehouses and workshops
- Outdoor areas requiring a combination of detailed views and panoramic coverage
Use the panoramic camera for broad areas and position the standard turret cameras where more focused monitoring is required.
Warranty
3 years product warranty.
