HiLook 8MP 4K CCTV Security System with 180° Panoramic Camera
Secure your home or business with this HiLook 6-camera 8MP 4K CCTV security system, featuring five HiLook IPC-T381H-MU Smart Hybrid Light turret cameras, one IPC-T289PH-MU/SL 8MP panoramic Active Deterrence camera and an 8-channel network video recorder (NVR).
This mixed-camera system combines detailed 4K surveillance with ultra-wide panoramic coverage. The five IPC-T381H-MU cameras provide individual views of selected areas, while the panoramic camera captures a 180° horizontal view to help monitor wider spaces such as driveways, entrances, shopfronts and car parks.
With AI-powered human and vehicle classification, Smart Hybrid Light technology, built-in microphones and additional deterrence features on the panoramic camera, this kit offers a flexible surveillance solution for residential and commercial properties.
Key Features
- 8MP 4K resolution: All six cameras capture high-resolution footage, with the panoramic model producing a 4256 × 1888 image.
- 180° panoramic coverage: The IPC-T289PH-MU/SL combines two lens images for an ultra-wide horizontal view.
- Smart Hybrid Light: The IPC-T381H-MU cameras and panoramic camera combine infrared and white-light illumination.
- AI human and vehicle classification: Helps distinguish people and vehicles from other movement.
- Perimeter protection: The IPC-T381H-MU cameras support line-crossing and intrusion detection.
- Active Deterrence: The panoramic camera features a built-in strobe light and speaker for audible warnings.
- Built-in audio: All cameras feature built-in microphones; the panoramic camera also supports two-way audio.
- 120dB True WDR: Helps balance bright and dark areas in challenging lighting.
- H.265+ compression: Helps reduce video storage and bandwidth requirements.
- IP67 protection: Both camera models feature weather-resistant housings for suitable outdoor installations.
- 8-channel NVR: Supports the six included cameras, with two channels remaining available for compatible additional cameras.
Camera Configuration
| Component | Quantity | Model |
|---|---|---|
| 8MP Smart Hybrid Light turret camera | 5 | HiLook IPC-T381H-MU |
| 8MP 180° panoramic Active Deterrence camera | 1 | HiLook IPC-T289PH-MU/SL |
| Network video recorder | 1 | 8-channel NVR |
HiLook IPC-T381H-MU 8MP Smart Hybrid Light Turret Cameras – 5 Units
The five IPC-T381H-MU cameras provide detailed surveillance for individual areas around your property. Their 8MP resolution captures 4K footage, while Smart Hybrid Light combines infrared and white-light illumination to support monitoring in different lighting conditions.
Key Features
- 8MP resolution – 3840 × 2160
- Smart Hybrid Light with IR and white-light illumination
- Night illumination up to 30 metres
- AI-based human and vehicle classification
- Line-crossing and intrusion detection
- 120dB True WDR
- Built-in arrayed dual microphone
- H.265+ video compression
- microSD card support up to 512GB
- PoE connectivity
- IP67 weather protection
- ONVIF compatibility
IPC-T381H-MU Technical Specifications
| Specification | Details |
|---|---|
| Model | HiLook IPC-T381H-MU |
| Camera Type | Fixed turret network camera |
| Resolution | 8MP – 3840 × 2160 |
| Image Sensor | 1/2.8-inch Progressive Scan CMOS |
| Lens Options | 2.8mm or 4mm fixed focal lens |
| Aperture | F1.6 |
| Wide Dynamic Range | 120dB True WDR |
| Illumination | Smart Hybrid Light – IR and white light |
| Illumination Range | Up to 30m |
| AI Detection | Human and vehicle classification |
| Perimeter Protection | Line crossing and intrusion detection |
| Audio | Built-in arrayed dual microphone |
| Storage | microSD/microSDHC/microSDXC up to 512GB; NAS; ANR |
| Compression | H.265+, H.265, H.264+, H.264 |
| PoE | IEEE 802.3af, Class 3 |
| Power | 12V DC or PoE |
| Network | 10/100Mbps Ethernet |
| Compatibility | ONVIF Profile S and G, ISAPI, SDK, ISUP |
| Weatherproof Rating | IP67 |
| Operating Temperature | -30°C to 60°C |
| Housing | Metal |
| Dimensions | Ø127.3 × 96.3mm |
| Weight | Approx. 515g |
| Warranty | 3 years |
HiLook IPC-T289PH-MU/SL 8MP 180° Panoramic Camera – 1 Unit
The IPC-T289PH-MU/SL is designed for locations that benefit from a broad field of view. Its dual 2mm lens configuration combines images into a panoramic view with a 180° horizontal field of view, helping monitor a wide area from one camera position.
Smart Hybrid Light combines infrared and white-light illumination up to 30 metres. The camera also features person and vehicle detection, a built-in microphone, a speaker and a strobe light for additional deterrence functionality.
Key Features
- 8MP panoramic resolution – 4256 × 1888
- 180° horizontal field of view
- Dual 2mm fixed lenses with stitched panoramic imaging
- Person and vehicle detection
- Smart Hybrid Light with IR and white-light illumination up to 30m
- Active Deterrence with strobe light and audible warning
- Built-in microphone and speaker
- Two-way audio support
- 120dB WDR
- microSD storage up to 512GB
- H.265+ video compression
- PoE support
- IP67 weather protection
- Hik-Connect and ONVIF support
IPC-T289PH-MU/SL Technical Specifications
| Specification | Details |
|---|---|
| Model | HiLook IPC-T289PH-MU/SL |
| Camera Type | Panoramic fixed turret IP camera |
| Resolution | 8MP – 4256 × 1888 |
| Image Sensor | 1/2.4-inch Progressive Scan CMOS |
| Field of View | 180° horizontal |
| Lens | Dual 2mm fixed focal lenses |
| Aperture | F1.6 |
| Night Illumination | Infrared and white light |
| Illumination Range | Up to 30m |
| Smart Hybrid Light | Supported |
| Wide Dynamic Range | 120dB |
| AI Detection | Person and vehicle detection |
| Smart Detection | Motion detection |
| Audio | Built-in microphone and speaker |
| Speaker Output | Up to 97dB |
| Two-Way Audio | Supported |
| Active Deterrence | Strobe light and audible warning |
| Storage | microSD/microSDHC/microSDXC up to 512GB |
| Compression | H.265+, H.265, H.264+, H.264 |
| Network Interface | RJ45 10/100Mbps |
| PoE | IEEE 802.3af, Class 3 |
| Power | 12V DC or PoE |
| Weatherproof Rating | IP67 |
| Material | Metal base with plastic cover |
| Dimensions | Ø138.3 × 115.4mm |
| Weight | Approx. 790g |
| Operating Temperature | -30°C to 60°C |
| Warranty | 3 years |
8-Channel Network Video Recorder
The included 8-channel NVR provides centralised recording and management for all six cameras in this kit.
Six channels are used by the supplied cameras, leaving two channels available for compatible additional IP cameras. Expansion depends on the exact NVR model, camera compatibility and available PoE power budget.
The exact NVR model has not been specified, so its detailed recording, networking, PoE and storage specifications should be confirmed before publishing.
What’s Included
- 5 × HiLook IPC-T381H-MU 8MP Smart Hybrid Light turret cameras
- 1 × HiLook IPC-T289PH-MU/SL 8MP 180° panoramic camera
- 1 × 8-channel network video recorder
Hard drive: Not included.
Ideal Applications
This mixed-camera CCTV system may suit:
- Residential driveways and front entrances
- Retail shops and shopfronts
- Offices and commercial buildings
- Car parks and building access points
- Warehouses and workshops
- Outdoor areas requiring broad panoramic coverage and focused camera views
Use the panoramic camera for wider spaces and position the standard turret cameras where more focused monitoring is required.
Warranty
3-year warranty.
