Complete 6-Camera 4K AcuSense & Colour Deterrence CCTV System

Secure your home, business, retail store, warehouse or commercial property with this complete HiLook 6-camera 8MP 4K CCTV system. This mixed-camera kit combines 5 × HiLook IPC-T381H-MU 8MP 4K AcuSense turret cameras with 1 × HiLook IPC-T289-MU/SL 8MP Colour Deterrence turret camera, all managed and recorded through the included HiLook NVR-108MH-C/8P 8-channel PoE NVR.

The five IPC-T381H-MU cameras provide high-resolution 4K surveillance with AcuSense human and vehicle classification, Smart Hybrid Light, 120dB True WDR and built-in dual microphones.

The IPC-T289-MU/SL adds enhanced active deterrence, featuring Smart Hybrid Light, human and vehicle classification, a built-in 110dB speaker, dual microphone and audible warning capabilities. This makes it particularly useful for a primary entrance, driveway or other high-priority area where active deterrence is desirable.

Key Features

• 5 × HiLook IPC-T381H-MU 8MP 4K AcuSense turret cameras
• 1 × HiLook IPC-T289-MU/SL 8MP 4K Colour Deterrence turret camera
• 1 × HiLook NVR-108MH-C/8P 8-channel PoE NVR
• All cameras provide 3840 × 2160 8MP resolution
• AcuSense human and vehicle classification
• Smart Hybrid Light with IR and white-light illumination
• Up to 30m illumination
• 120dB True WDR
• Built-in arrayed dual microphone on all included cameras
• 110dB built-in speaker on the IPC-T289-MU/SL
• Active audio deterrence on the IPC-T289-MU/SL
• Line crossing and intrusion detection
• H.265+ compression
• microSD storage support
• PoE / PoE+ connectivity
• IP67 weather-resistant metal camera housings
• ONVIF compatibility
• 8-channel synchronous playback
• Up to 8MP recording support
• 3-year warranty

Camera Configuration

Total cameras: 6
NVR channels: 8
Channels used: 6
Remaining channels: 2

5 × HiLook IPC-T381H-MU 8MP 4K AcuSense Turret Cameras

The HiLook IPC-T381H-MU provides detailed 8MP 4K surveillance together with intelligent detection and flexible night illumination.

Its 1/2.8" Progressive Scan CMOS sensor produces 3840 × 2160 video, making it suitable for applications where clear image detail is important.

AcuSense AI Detection

The IPC-T381H-MU uses deep-learning technology for human and vehicle classification, helping identify relevant movement while reducing unnecessary alerts from general motion.

It also supports:

• Human classification
• Vehicle classification
• Line crossing detection
• Intrusion detection
• Perimeter protection

Smart Hybrid Light

The camera combines IR and white-light illumination with coverage of up to 30 metres.

Smart Hybrid Light provides flexible night-time surveillance, with supplemental white-light illumination available when supported conditions require additional visible lighting.

120dB True WDR

With 120dB True WDR, the camera is designed to maintain useful image detail in challenging lighting conditions, including areas with strong backlighting or significant contrast between bright and dark areas.

Built-In Audio

Each IPC-T381H-MU includes an arrayed dual microphone, providing built-in audio capture as part of the camera.

IPC-T381H-MU Technical Specifications

1 × HiLook IPC-T289-MU/SL 8MP 4K Colour Deterrence Camera

The HiLook IPC-T289-MU/SL adds an active deterrence layer to this mixed-camera system while maintaining the same high-resolution 8MP / 4K image quality.

It features a 1/2.8" Progressive Scan CMOS sensor, 3840 × 2160 resolution and 120dB True WDR for detailed surveillance in challenging lighting conditions.

Smart Hybrid Light & Colour Deterrence

The IPC-T289-MU/SL combines IR and white-light illumination with a range of up to 30 metres.

White-light illumination can provide additional visible lighting under supported security-event conditions, helping produce colour footage during relevant events while also providing a visible deterrence effect.

Active Audio Deterrence

The key advantage of the IPC-T289-MU/SL is its integrated deterrence hardware.

It includes:

• Built-in speaker rated up to 110dB
• Arrayed dual microphone
• Audible warning capability
• Customisable warning messages/audio
• Human and vehicle classification
• Line crossing detection
• Intrusion detection

This makes the camera particularly useful for locations where you want an active response to detected security events.

IPC-T289-MU/SL Technical Specifications

HiLook NVR-108MH-C/8P 8-Channel PoE NVR

The included HiLook NVR-108MH-C/8P provides centralised recording, playback and management for all six cameras.

The NVR supports IP cameras up to 8MP / 4K, making it suitable for recording the high-resolution footage from both the IPC-T381H-MU and IPC-T289-MU/SL cameras.

Its eight integrated PoE ports allow compatible cameras to connect directly to the NVR over Ethernet.

NVR Key Features

• 8-channel IP video input
• Supports cameras up to 8MP / 4K
• 80Mbps incoming bandwidth
• 80Mbps outgoing bandwidth
• Recording resolution up to 8MP
• 8-channel synchronous playback
• H.265+ / H.265 / H.264+ / H.264 compression
• 8 × RJ45 10/100Mbps PoE ports
• IEEE 802.3af/at PoE support
• Total PoE budget up to 75W
• 1 × Gigabit network port
• Up to 64 remote connections
• 1 × SATA HDD bay
• Supports up to 8TB HDD capacity
• HDMI output up to 4K
• VGA output up to 1920 × 1080
• 2 × USB 2.0 ports
• Hik-Connect, iVMS-4200 and HiLookVision support
• ONVIF-compatible
• Camera-side VCA support
• 3-year warranty

NVR-108MH-C/8P Technical Specifications

What’s Included

• 5 × HiLook IPC-T381H-MU 8MP 4K AcuSense Turret Cameras
• 1 × HiLook IPC-T289-MU/SL 8MP 4K Colour Deterrence Turret Camera
• 1 × HiLook NVR-108MH-C/8P 8-Channel PoE NVR

HDD Not Included

A hard drive is not included in this kit unless specifically stated otherwise.

The NVR features 1 × SATA interface and supports up to 8TB HDD capacity.

Channel Configuration

This kit uses 6 of the NVR's 8 available channels, leaving 2 channels available for compatible additional IP cameras, subject to compatibility and the NVR's available PoE budget.

The NVR has a maximum total PoE budget of 75W, so any additional cameras must remain within the specified PoE capacity.

Ideal Applications

This mixed 8MP CCTV system is suitable for:

• Homes
• Driveways
• Front and rear entrances
• Retail stores
• Shops
• Warehouses
• Offices
• Workshops
• Commercial properties
• Building perimeters
• Car parks
• High-priority security areas requiring active deterrence

Why Choose This Mixed HiLook CCTV Kit?

This configuration combines five AcuSense 4K cameras for general high-resolution surveillance with one IPC-T289-MU/SL Colour Deterrence camera for an area where active audio and visible deterrence are especially valuable.

The result is a flexible six-camera system offering 8MP 4K imaging, AI human and vehicle classification, Smart Hybrid Light, 120dB WDR and built-in audio, with additional active deterrence available from the T289 camera.

The included 8-channel PoE NVR provides centralised recording and management while leaving two channels available for compatible expansion, subject to the NVR's specifications and PoE budget.

Warranty

3-Year Warranty on the supplied HiLook cameras and NVR.
