Secure your property with this HiLook 4 Camera CCTV Kit, combining three 8MP AcuSense Smart Hybrid Light turret cameras with one 8MP Colour Deterrence turret camera and a 4-channel PoE NVR.

The three HiLook IPC-T381H-MU cameras provide detailed 4K surveillance with AcuSense human and vehicle classification, Smart Hybrid Light illumination, 120dB True WDR and built-in dual-microphone audio recording. Their IP67-rated metal housing makes them suitable for residential and commercial indoor or outdoor installations.

The included HiLook IPC-T289-MU/SL adds active colour deterrence, combining 8MP 4K imaging with Smart Hybrid Light, human and vehicle classification, a built-in 110dB speaker, dual microphone and audible warning functionality.

The HiLook NVR-104MH-C/4P provides four IP camera channels and four integrated PoE ports, allowing all four cameras to connect directly to the recorder for simplified installation. It supports up to 8MP camera resolution, 4K HDMI output, H.265+ compression and up to 8TB of HDD storage.

What's Included

• 3 × HiLook IPC-T381H-MU
  • 8MP 4K AcuSense Smart Hybrid Light Turret Camera
• 1 × HiLook IPC-T289-MU/SL
  • 8MP 4K Colour Deterrence Smart Hybrid Light Turret Camera
• 1 × HiLook NVR-104MH-C/4P
  • 4-Channel 4K PoE NVR
• HDD: Not included

3 × HiLook IPC-T381H-MU – 8MP AcuSense Smart Hybrid Light Cameras

The three IPC-T381H-MU cameras provide high-resolution 4K surveillance with intelligent human and vehicle classification. Smart Hybrid Light combines infrared and white-light illumination for flexible night-time monitoring.

Key Features

• 8MP 4K resolution
• 3840 × 2160 resolution
• 1/2.8" Progressive Scan CMOS
• 2.8mm or 4mm fixed-focal lens options
• F1.6 aperture
• 120dB True WDR
• Smart Hybrid Light
• Up to 30m IR and white-light illumination
• AcuSense deep-learning human and vehicle classification
• Line crossing and intrusion detection
• Built-in arrayed dual microphone
• One-way audio recording
• H.265 / H.264 / H.265+ / H.264+
• microSD/microSDHC/microSDXC support up to 512GB
• NAS and ANR support
• IEEE 802.3af PoE
• 12V DC or PoE
• ONVIF Profile S & G
• IP67 weatherproof metal housing
• Operating temperature –30°C to +60°C
• 3-year warranty

T381H-MU Technical Specifications

1 × HiLook IPC-T289-MU/SL – 8MP Colour Deterrence Camera

The IPC-T289-MU/SL provides an additional layer of active deterrence within the kit. Along with 8MP 4K imaging and Smart Hybrid Light, it includes human and vehicle classification, line crossing and intrusion detection, plus a built-in speaker for audible warnings.

Key Features

• 8MP 4K resolution
• 3840 × 2160 resolution
• 1/2.8" Progressive Scan CMOS
• 2.8mm / 4mm fixed-focal lens options
• F1.6 aperture
• 120dB True WDR
• Smart Hybrid Light
• Up to 30m IR and white-light illumination
• Human and vehicle classification
• Line crossing and intrusion detection
• Built-in arrayed dual microphone
• Built-in speaker up to 110dB
• Audible warning and custom audio support
• microSD storage up to 512GB
• NAS and ANR support
• H.265 / H.264 / H.265+ / H.264+
• IEEE 802.3at PoE+
• 12VDC or PoE+
• ONVIF Profile S/G
• IP67 metal housing
• Operating temperature –30°C to +60°C

T289-MU/SL Technical Specifications

HiLook NVR-104MH-C/4P – 4-Channel 4K PoE NVR

The HiLook NVR-104MH-C/4P provides the recording and management platform for all four cameras in this kit. With four built-in PoE ports, each compatible camera can connect directly to the recorder using a single Ethernet cable for both power and data.

Key Features

• 4-channel IP video recording
• Supports cameras up to 8MP / 4K
• 4 built-in RJ45 PoE ports
• IEEE 802.3af/at PoE support
• Up to 50W total PoE budget
• 40Mbps incoming bandwidth
• 80Mbps outgoing bandwidth
• H.265+ / H.265 / H.264+ / H.264 compression
• Up to 1-channel 8MP @ 30fps decoding
• Up to 5-channel 1080p @ 30fps decoding
• 4-channel synchronous playback
• HDMI output up to 4096 × 2160 @ 30Hz
• VGA output up to 1920 × 1080 @ 60Hz
• 1 × SATA HDD bay
• Supports up to 8TB HDD
• Camera-side smart analytics support
• ONVIF compatibility
• HiLookVision, Hik-Connect and iVMS-4200 support
• Compact design
• 3-year warranty

NVR Technical Specifications

Important: The hard drive is not included with the NVR and must be purchased separately.

Kit Configuration

Why Choose This 4-Camera HiLook Kit?

This configuration combines three general-purpose 8MP AcuSense cameras with one 8MP active colour-deterrence camera.

The three T381H-MU cameras are suited to general surveillance areas such as driveways, entrances, retail areas and property surroundings. The T289-MU/SL can be positioned at a higher-priority location where its built-in speaker, audio deterrence and Smart Hybrid Light provide additional security functionality.

The four cameras match the four PoE ports and four recording channels of the included NVR, providing a complete 4-camera PoE CCTV configuration.

Ideal Applications

• Homes
• Driveways
• Entrances
• Small businesses
• Retail stores
• Offices
• Warehouses
• Workshops
• Commercial properties
• Property perimeters
• Small CCTV installations
