HiLook 4-Camera 6MP Smart Hybrid Light CCTV Kit | 4 × IPC-T363H-MU + 4CH PoE NVR

Protect your home or business with this complete HiLook 4-camera 6MP CCTV security system, featuring four IPC-T363H-MU Smart Hybrid Light turret cameras and a 4-channel PoE NVR.

Designed for reliable day and night surveillance, this HiLook CCTV kit delivers detailed 6MP resolution, intelligent human and vehicle classification, Smart Hybrid Light illumination and weather-resistant outdoor protection.

Each IPC-T363H-MU camera features a fast F1.2 aperture and 120dB True WDR, helping provide clear and detailed images in varying lighting conditions. Smart Hybrid Light combines infrared and white-light illumination for flexible night-time monitoring, with up to 30m illumination.

The included HiLook NVR-104MH-C/4P 4-channel PoE NVR provides centralised recording and management, with four integrated PoE ports for a convenient camera connection.

Kit Highlights

• Complete 4-camera 6MP CCTV security system
• 4 × HiLook IPC-T363H-MU Smart Hybrid Light turret cameras
• 1 × HiLook NVR-104MH-C/4P 4-channel PoE NVR
• 6MP resolution — 3200 × 1800
• Smart Hybrid Light — IR + white light
• Up to 30m illumination
• AI human and vehicle classification
• Line crossing and intrusion detection
• Fast F1.2 aperture
• 120dB True WDR
• Built-in microphones
• H.265+ video compression
• IEEE 802.3af PoE
• IP67-rated metal camera housings
• ONVIF compatibility
• 4K-capable NVR
• 3-year warranty
• Hard drive not included

4 × HiLook IPC-T363H-MU 6MP Smart Hybrid Light Cameras

The HiLook IPC-T363H-MU is a 6MP Smart Hybrid Light turret camera designed for dependable surveillance across residential and commercial environments.

Its 3200 × 1800 resolution provides detailed video, while the fast F1.2 aperture helps capture brighter images in low-light conditions.

The camera's Smart Hybrid Light technology combines infrared and white-light illumination. This allows the camera to provide discreet IR night vision while also using white light when additional colour illumination is required.

With up to 30m illumination, the cameras are suitable for monitoring entrances, driveways, pathways, yards, car parks and other areas requiring dependable day and night coverage.

Intelligent human and vehicle classification helps focus detection on relevant targets, while line crossing and intrusion detection provide additional security monitoring capabilities.

IPC-T363H-MU Features

• 6MP resolution — 3200 × 1800
• 1/2.4" Progressive Scan CMOS
• 2.8mm / 4mm fixed lens options
• Fast F1.2 aperture
• 120dB True WDR
• Smart Hybrid Light — IR + white light
• Up to 30m illumination
• Human and vehicle classification
• Line crossing and intrusion detection
• Built-in microphone
• Environmental noise filtering
• H.265+ / H.265 / H.264+ / H.264
• IEEE 802.3af PoE
• IP67-rated metal housing
• ONVIF Profile S/T
• -30°C to 60°C operating temperature
• Approx. 600g
• 3-year warranty

HiLook 4-Channel PoE NVR

The included HiLook NVR-104MH-C/4P provides centralised recording, playback and management for all four 6MP CCTV cameras.

The NVR supports IP cameras up to 8MP / 4K, providing sufficient resolution support for the 6MP cameras included in this kit.

With four integrated PoE ports, each camera can connect directly to the NVR using a single network cable for data and power, helping simplify installation.

The NVR also supports remote viewing through compatible HiLookVision, Hik-Connect and iVMS-4200 platforms.

NVR Features

• 4 IP camera channels
• Supports cameras up to 8MP / 4K
• 4 built-in PoE ports
• IEEE 802.3af/at
• Up to 50W total PoE budget
• 4K HDMI output
• H.265+ / H.265 / H.264+ / H.264
• Up to 40Mbps incoming bandwidth
• Up to 80Mbps outgoing bandwidth
• 4-channel synchronous playback
• 1 × SATA HDD bay
• Supports HDDs up to 8TB
• ONVIF compatible
• HiLookVision / Hik-Connect / iVMS-4200 remote viewing
• 2 × USB 2.0
• 10/100Mbps network interface
• 3-year warranty

Kit Specifications

What's Included

• 4 × HiLook IPC-T363H-MU 6MP Smart Hybrid Light turret cameras
• 1 × HiLook NVR-104MH-C/4P 4-channel PoE NVR
• Standard camera mounting accessories as supplied
• NVR power supply and standard accessories

Hard drive is not included unless an HDD option is selected separately.

Ideal Applications

This HiLook 4-camera 6MP CCTV system is suitable for:

• Homes and residential properties
• Driveways and entrances
• Front and rear yards
• Gates and pathways
• Retail stores
• Offices
• Workshops
• Warehouses
• Small businesses
• Commercial properties
• Outdoor areas requiring day and night surveillance

Important Notes

The included NVR has 4 camera channels, matching the four IPC-T363H-MU cameras supplied with this kit.

The IPC-T363H-MU cameras use IEEE 802.3af PoE, while the NVR supports IEEE 802.3af/at with a 50W total PoE budget.

An HDD is required for NVR video recording and is not included as standard. microSD cards are also not included unless separately specified.

Lens options may vary depending on the selected camera configuration. Please select or confirm the required lens option before ordering where applicable.
