HiLook 4-Camera 6MP CCTV Kit | 3 × Smart Hybrid Light 363 + 1 × Active Deterrence 269 + 4CH PoE NVR

Protect your home or business with this complete HiLook 4-camera 6MP CCTV system, featuring three IPC-T363H-MU Smart Hybrid Light turret cameras, one IPC-T269H-MU/SL Active Deterrence turret camera, and a 4-channel PoE NVR.

This kit combines high-resolution 6MP surveillance, intelligent human and vehicle detection, Smart Hybrid Light night vision and active security features. The IPC-T363H-MU cameras provide reliable day-and-night monitoring with a fast F1.2 aperture, while the IPC-T269H-MU/SL adds Smart Dual-Light, red and blue warning strobe, audible alarm and two-way audio.

The included 4-channel PoE NVR provides centralized recording and management, with four integrated PoE ports for convenient camera connectivity.

Kit Highlights

• 4 × HiLook 6MP CCTV cameras
• 3 × IPC-T363H-MU 6MP Smart Hybrid Light turret cameras
• 1 × IPC-T269H-MU/SL 6MP Active Deterrence turret camera
• 1 × HiLook NVR-104MH-C/4P 4-channel PoE NVR
• 6MP resolution — 3200 × 1800
• Smart Hybrid Light on IPC-T363H-MU cameras
• Smart Dual-Light and active deterrence on IPC-T269H-MU/SL
• Up to 30m illumination
• AI human and vehicle classification
• 120dB True WDR
• Built-in microphones
• Two-way audio and 95dB speaker on IPC-T269H-MU/SL
• Red and blue warning strobe
• H.265+ video compression
• PoE connectivity
• IP67 weatherproof metal camera housings
• ONVIF compatibility
• 3-year warranty
• Hard drive not included

3 × HiLook IPC-T363H-MU 6MP Smart Hybrid Light Cameras

The HiLook IPC-T363H-MU cameras provide detailed 6MP surveillance with a fast F1.2 aperture, helping deliver brighter images in low-light conditions.

Smart Hybrid Light combines infrared and white-light illumination, allowing the cameras to monitor discreetly using IR and activate white light when an event occurs. Up to 30m illumination provides coverage for entrances, driveways, pathways and other areas.

Deep-learning human and vehicle classification helps reduce false alarms from non-target movement, while line crossing and intrusion detection provide additional perimeter monitoring.

IPC-T363H-MU Features

• 6MP resolution — 3200 × 1800
• 1/2.4" Progressive Scan CMOS
• 2.8mm / 4mm fixed lens options
• Fast F1.2 aperture
• 120dB True WDR
• Smart Hybrid Light — IR + white light
• Up to 30m illumination
• Human and vehicle classification
• Line crossing and intrusion detection
• Built-in microphone with environmental noise filtering
• H.265+/H.265/H.264+/H.264
• IEEE 802.3af PoE
• IP67 metal housing
• ONVIF Profile S/T
• 3-year warranty

1 × HiLook IPC-T269H-MU/SL 6MP Active Deterrence Camera

The IPC-T269H-MU/SL adds active deterrence capability to the system. Its 6MP sensor captures 3200 × 1800 video, while 120dB True WDR helps maintain detail in difficult lighting conditions.

Its Smart Dual-Light system uses IR for discreet night surveillance and white light when colour illumination is required. The camera can also use its integrated red and blue strobe and audible alarm to help deter unwanted activity.

A built-in microphone and 95dB speaker provide two-way audio for remote communication through compatible systems.

IPC-T269H-MU/SL Features

• 6MP resolution — 3200 × 1800
• 1/2.4" Progressive Scan CMOS
• 2.8mm / 4mm / 6mm fixed lens options
• F1.6 aperture
• 120dB True WDR
• Smart Dual-Light
• Up to 30m IR and white-light illumination
• Human and vehicle classification
• Line crossing and intrusion detection
• Red and blue warning strobe
• Audible alarm
• Built-in microphone
• 95dB speaker
• Two-way audio
• microSD storage up to 256GB
• NAS support
• H.265+ compression
• IEEE 802.3af PoE
• IP67 metal housing
• -30°C to 60°C operating temperature
• Approx. 820g

4-Channel HiLook PoE NVR

The included HiLook NVR-104MH-C/4P provides recording and management for all four cameras.

It supports IP cameras up to 8MP / 4K, meaning the NVR has sufficient resolution support for the four 6MP cameras included in this kit. Four integrated PoE ports provide a convenient connection point for the cameras.

NVR Features

• 4 IP camera channels
• Supports up to 8MP / 4K cameras
• 4 built-in PoE ports
• IEEE 802.3af/at
• Up to 50W total PoE budget
• 4K HDMI output
• H.265+/H.265/H.264+/H.264
• Up to 40Mbps incoming bandwidth
• Up to 80Mbps outgoing bandwidth
• 4-channel synchronous playback
• 1 × SATA HDD bay
• Supports HDD up to 8TB
• ONVIF compatible
• HiLookVision / Hik-Connect / iVMS-4200 remote viewing
• 2 × USB 2.0
• 10/100Mbps network interface
• 3-year warranty

Kit Specifications

What's Included

• 3 × HiLook IPC-T363H-MU 6MP Smart Hybrid Light cameras
• 1 × HiLook IPC-T269H-MU/SL 6MP Active Deterrence camera
• 1 × HiLook NVR-104MH-C/4P 4-channel PoE NVR
• Standard camera mounting accessories as supplied
• NVR power supply and standard accessories

Hard drive is not included unless an HDD option is selected separately.

Ideal Applications

This CCTV kit is suitable for:

• Homes and residential properties
• Driveways and entrances
• Gates and pathways
• Retail stores
• Offices
• Workshops
• Warehouses
• Small businesses
• Commercial properties
• Outdoor areas requiring active deterrence

Important Notes

The included NVR has 4 camera channels, matching the four cameras supplied in this kit.

The IPC-T363H-MU cameras use IEEE 802.3af PoE, while the IPC-T269H-MU/SL also uses IEEE 802.3af PoE. The included NVR supports IEEE 802.3af/at with a 50W total PoE budget.

An HDD is required for NVR recording and is not included as standard. microSD cards are also not included unless separately specified.

Active deterrence functions on the IPC-T269H-MU/SL should be configured appropriately for the installation environment and local requirements.
