Complete HiLook 6MP CCTV security system featuring four AcuSense AI turret cameras and a 4-channel PoE NVR. Designed for homes, small businesses, retail stores, offices, restaurants and other properties requiring reliable high-resolution surveillance with intelligent human and vehicle detection.

What's Included

Key Features

• 4 × 6MP AcuSense AI cameras
• 3200 × 1800 resolution for detailed surveillance footage
• Human and vehicle classification to help reduce false alarms
• 120dB True WDR for challenging lighting conditions
• DarkFighter technology for improved low-light performance
• Up to 30m IR night vision
• Built-in dual microphones for audio recording
• H.265+ compression for efficient storage and bandwidth usage
• 4 × integrated PoE ports on the NVR
• Up to 50W PoE power budget
• 4K HDMI output
• Up to 8MP camera support
• 4-channel synchronous playback
• microSD support up to 512GB on each camera
• IP67-rated metal camera housing
• ONVIF compatibility
• Remote viewing via compatible HiLook/Hikvision platforms
• 1 × SATA HDD bay up to 8TB
• 3-year warranty

HiLook 6MP AcuSense AI Turret Cameras

The HiLook IPC-T361H-MU cameras provide 6MP resolution at 3200 × 1800, delivering detailed footage for monitoring entrances, driveways, retail areas, offices and building perimeters.

The integrated AcuSense deep-learning technology can classify humans and vehicles, helping reduce unnecessary alerts caused by other moving objects such as animals, vegetation and environmental movement.

AI Detection

Supported intelligent functions include:

• Human classification
• Vehicle classification
• Line crossing detection
• Intrusion detection
• Motion detection
• AcuSense false-alarm reduction

This makes the cameras suitable for installations where distinguishing people and vehicles from general movement is important.

120dB True WDR

The cameras feature 120dB True WDR, helping maintain usable image detail when bright and dark areas appear within the same scene.

This is particularly useful for:

• Entrances
• Doorways
• Driveways
• Shopfronts
• Areas exposed to sunlight
• Indoor areas facing bright windows

Night Vision

Each camera provides up to 30 metres of IR night vision, allowing continuous surveillance in low-light and dark environments.

Built-in Dual Microphone

The IPC-T361H-MU features an arrayed dual microphone, allowing audio to be recorded alongside video.

This provides additional context to recorded footage where audio monitoring is appropriate.

Efficient H.265+ Compression

The cameras support H.265+, helping reduce storage and network bandwidth requirements compared with older compression formats while maintaining video quality.

HiLook 4-Channel 4K PoE NVR

The included HiLook NVR-104MH-C/4P is designed for compact CCTV installations and supports up to four IP cameras with resolutions up to 8MP/4K.

With four integrated PoE ports, each camera can be connected directly to the NVR using a single Ethernet cable for both power and network communication.

4K Recording Support

The NVR supports cameras up to 8MP (4K) and can handle a range of resolutions including:

• 8MP / 4K
• 6MP
• 5MP
• 4MP
• 3MP
• 1080p
• Lower resolutions

The recorder provides 40Mbps incoming bandwidth and 80Mbps outgoing bandwidth.

Built-in 4-Port PoE

The NVR includes:

• 4 × RJ45 10/100Mbps PoE ports
• IEEE 802.3af/at support
• Up to 50W total PoE budget
• Direct camera connection
• Single-cable power and data

This simplifies installation by eliminating the need for separate power supplies for compatible cameras.

4K HDMI Output

The NVR supports high-resolution local display through HDMI, with output up to 4096 × 2160 / 3840 × 2160 at 30Hz.

VGA output supports up to 1920 × 1080 at 60Hz.

Storage

The NVR includes one SATA HDD bay supporting up to 8TB.

Hard drive is not included and must be purchased separately.

The recorder also supports 4-channel synchronous playback, allowing footage from all four cameras to be reviewed simultaneously.

Technical Specifications — IPC-T361H-MU

Technical Specifications — NVR-104MH-C/4P

Ideal Applications

This 4-camera HiLook system is suitable for:

• Homes
• Small offices
• Retail stores
• Restaurants
• Small warehouses
• Workshops
• Small commercial properties
• Driveways and entrances
• Small building perimeters

Important Notes

• Hard drive is not included with the NVR.
• Network cabling and installation are not included.
