HiLook 4-Camera CCTV Kit | 3 × 6MP 361 AcuSense + 1 × 6MP 269 Colour Deterrence + 4CH PoE NVR

Secure your home or business with this complete HiLook 4-camera 6MP CCTV system, combining three 6MP AcuSense turret cameras with one 6MP Active Deterrence turret camera and a 4-channel PoE NVR.

The system provides detailed 6MP surveillance, AI-powered human and vehicle classification, night vision, audio recording and active deterrence. The IPC-T269H-MU/SL adds an additional layer of protection with Smart Dual-Light, red and blue warning strobe, audible alarm and two-way audio.

With built-in PoE connectivity on the NVR, the cameras can be connected using network cables for both power and video transmission, making installation straightforward for residential and small-business security systems.

Kit Highlights

• 4 × 6MP HiLook CCTV cameras
• 3 × IPC-T361H-MU 6MP AcuSense turret cameras
• 1 × IPC-T269H-MU/SL 6MP Active Deterrence turret camera
• 1 × HiLook NVR-104MH-C/4P 4-channel PoE NVR
• 6MP resolution up to 3200 × 1800
• AI human and vehicle classification
• Smart Dual-Light on the active deterrence camera
• Up to 30m IR/white-light illumination
• 120dB True WDR
• Active red/blue warning strobe
• Audible alarm and two-way audio on IPC-T269H-MU/SL
• Built-in microphones on supported cameras
• PoE camera installation
• IP67 weather-resistant camera housings
• H.265+ video compression
• Remote viewing through compatible HiLook/Hikvision platforms
• Hard drive not included unless selected separately

3 × HiLook IPC-T361H-MU 6MP AcuSense Turret Cameras

The three HiLook IPC-T361H-MU cameras provide reliable 6MP surveillance with intelligent human and vehicle classification. AcuSense technology helps identify relevant targets and reduce false alarms caused by non-target movement.

With 120dB True WDR and up to 30m IR night vision, these cameras are suitable for monitoring entrances, driveways, retail areas, offices, warehouses and other indoor or outdoor locations.

IPC-T361H-MU Features

• 6MP resolution — 3200 × 1800
• 1/2.4" Progressive Scan CMOS
• 2.8mm / 4mm fixed lens options
• F1.6 aperture
• 120dB True WDR
• Up to 30m IR night vision
• Human and vehicle classification
• Line crossing and intrusion detection
• Built-in arrayed dual microphone
• microSD storage up to 512GB
• NAS and ANR support
• H.265/H.264/H.265+/H.264+
• IEEE 802.3af PoE
• IP67 metal housing
• ONVIF Profile S & G
• 3-year warranty

1 × HiLook IPC-T269H-MU/SL 6MP Active Deterrence Camera

The HiLook IPC-T269H-MU/SL adds active security features to the system. Its 6MP sensor delivers 3200 × 1800 resolution, while Smart Dual-Light combines infrared and white-light illumination for effective night surveillance.

When a security event is detected, the camera can use its white-light illumination, red/blue warning strobe and audible alarm to actively deter unwanted activity.

The built-in microphone and 95dB speaker also support two-way audio, allowing users to communicate remotely through compatible systems.

IPC-T269H-MU/SL Features

• 6MP resolution — 3200 × 1800
• 1/2.4" Progressive Scan CMOS
• 2.8mm / 4mm / 6mm fixed lens options
• F1.6 aperture
• 120dB True WDR
• Smart Dual-Light technology
• Up to 30m IR and white-light illumination
• Human and vehicle classification
• Red and blue warning strobe
• Audible alarm
• Built-in microphone
• 95dB speaker
• Two-way audio
• microSD storage up to 256GB
• NAS support
• H.265+ compression
• IEEE 802.3af PoE
• ONVIF Profile S/G/T
• IP67 metal housing
• -30°C to 60°C operating temperature
• Approx. 820g

4-Channel HiLook PoE NVR

The included HiLook NVR-104MH-C/4P provides recording and management for all four cameras. It supports IP cameras up to 8MP / 4K, giving the NVR sufficient resolution support for the four 6MP cameras in this kit.

Four integrated PoE ports provide a convenient connection point for the cameras while supplying network connectivity and power.

NVR Key Features

• 4 IP camera channels
• Supports up to 8MP / 4K cameras
• 4 built-in PoE ports
• IEEE 802.3af/at
• Up to 50W total PoE budget
• 4K HDMI output
• H.265+/H.265/H.264+/H.264
• Up to 40Mbps incoming bandwidth
• Up to 80Mbps outgoing bandwidth
• 4-channel synchronous playback
• 1 × SATA HDD bay
• Supports HDD up to 8TB
• ONVIF compatible
• HiLookVision / Hik-Connect / iVMS-4200 remote viewing
• 2 × USB 2.0
• 10/100Mbps network interface
• 3-year warranty

Kit Specifications

What's Included

• 3 × HiLook IPC-T361H-MU 6MP AcuSense turret cameras
• 1 × HiLook IPC-T269H-MU/SL 6MP Active Deterrence turret camera
• 1 × HiLook NVR-104MH-C/4P 4-channel PoE NVR
• Standard camera mounting accessories as supplied
• NVR power supply and accessories as supplied

Hard drive is not included unless an HDD option is selected.

Ideal Applications

This kit is suitable for:

• Homes and residential properties
• Driveways and entrances
• Offices
• Retail stores
• Workshops
• Warehouses
• Small commercial premises
• Building entrances
• Business security installations

Important Notes

The included NVR provides 4 camera channels, matching the four cameras supplied in this kit.

The IPC-T269H-MU/SL uses PoE (IEEE 802.3af), while the NVR supports IEEE 802.3af/at PoE. Always ensure the total connected camera power requirements remain within the NVR's 50W PoE budget.

An HDD is required for NVR-based recording and is not included as standard.

The IPC-T269H-MU/SL provides active deterrence features such as the strobe, audible alarm and two-way audio. These features should be configured according to the installation environment and local requirements.
