HiLook 4-Camera 6MP CCTV Kit | 2 × Smart Hybrid Light 363 + 2 × Active Deterrence 269 + 4CH PoE NVR

Protect your home or business with this HiLook 4-camera 6MP CCTV security system, combining 2 × IPC-T363H-MU Smart Hybrid Light turret cameras, 2 × IPC-T269H-MU/SL Active Deterrence turret cameras, and a 4-channel PoE NVR.

Designed for reliable day and night surveillance, this 6MP CCTV camera system delivers detailed 3200 × 1800 video, intelligent human and vehicle classification, advanced night illumination and weather-resistant outdoor protection.

The IPC-T363H-MU cameras feature Smart Hybrid Light technology and a fast F1.2 aperture for improved low-light performance. The IPC-T269H-MU/SL cameras add active deterrence features including Smart Dual-Light, red and blue warning strobe, audible alarm, built-in microphone and two-way audio.

The included HiLook NVR-104MH-C/4P 4-channel PoE NVR provides centralised video recording and camera management, with four integrated PoE ports for a straightforward installation.

Key Features

• Complete 4-camera 6MP CCTV security system
• 2 × HiLook IPC-T363H-MU Smart Hybrid Light turret cameras
• 2 × HiLook IPC-T269H-MU/SL Active Deterrence turret cameras
• 1 × HiLook NVR-104MH-C/4P 4-channel PoE NVR
• 6MP resolution — 3200 × 1800
• AI human and vehicle classification
• Smart Hybrid Light and Smart Dual-Light technology
• Up to 30m IR/white-light illumination
• 120dB True WDR
• Active deterrence with red and blue strobe and audible alarm
• Built-in microphones
• Two-way audio on IPC-T269H-MU/SL cameras
• H.265+ video compression
• PoE connectivity for simplified installation
• IP67-rated weather-resistant metal camera housings
• ONVIF compatibility
• Suitable for residential and commercial surveillance
• 3-year warranty
• Hard drive not included

2 × HiLook IPC-T363H-MU 6MP Smart Hybrid Light Cameras

The HiLook IPC-T363H-MU 6MP CCTV camera provides high-resolution surveillance with a fast F1.2 aperture, helping capture clearer and brighter images in challenging low-light conditions.

Its Smart Hybrid Light technology combines infrared and white-light illumination. The camera can provide discreet IR night vision while also using white light when colour illumination is required.

With up to 30m illumination, the IPC-T363H-MU is suitable for monitoring driveways, entrances, pathways, yards and other indoor or outdoor areas.

Intelligent human and vehicle classification helps distinguish relevant targets from general movement, while line crossing and intrusion detection provide additional security monitoring capabilities.

IPC-T363H-MU Features

• 6MP resolution — 3200 × 1800
• 1/2.4" Progressive Scan CMOS
• 2.8mm / 4mm fixed lens options
• Fast F1.2 aperture
• 120dB True WDR
• Smart Hybrid Light — IR + white light
• Up to 30m illumination
• Human and vehicle classification
• Line crossing and intrusion detection
• Built-in microphone with environmental noise filtering
• H.265+ / H.265 / H.264+ / H.264
• IEEE 802.3af PoE
• IP67-rated metal housing
• ONVIF Profile S/T
• 3-year warranty

2 × HiLook IPC-T269H-MU/SL 6MP Active Deterrence Cameras

The HiLook IPC-T269H-MU/SL adds advanced active deterrence to this CCTV system. Its 6MP sensor provides detailed 3200 × 1800 video, while 120dB True WDR helps retain image detail in areas with challenging lighting conditions.

The camera's Smart Dual-Light system combines IR and white-light illumination for effective day and night surveillance. When configured for deterrence, the integrated red and blue warning strobe and audible alarm can help draw attention to detected activity.

A built-in microphone and 95dB speaker also support two-way audio, allowing compatible users to communicate remotely through the camera.

IPC-T269H-MU/SL Features

• 6MP resolution — 3200 × 1800
• 1/2.4" Progressive Scan CMOS
• 2.8mm / 4mm / 6mm fixed lens options
• F1.6 aperture
• 120dB True WDR
• Smart Dual-Light technology
• Up to 30m IR and white-light illumination
• Human and vehicle classification
• Line crossing and intrusion detection
• Red and blue warning strobe
• Audible alarm
• Built-in microphone
• 95dB speaker
• Two-way audio
• microSD storage up to 256GB
• NAS support
• H.265+ compression
• IEEE 802.3af PoE
• IP67-rated metal housing
• -30°C to 60°C operating temperature
• Approx. 820g

HiLook 4-Channel PoE NVR

The included HiLook NVR-104MH-C/4P provides centralised recording, playback and management for all four cameras.

Supporting IP cameras up to 8MP / 4K, the NVR is suitable for the 6MP cameras supplied in this kit. Its four integrated PoE ports allow the cameras to connect directly to the NVR, helping simplify cabling and installation.

The NVR also supports remote viewing through compatible HiLook and Hikvision platforms, allowing users to monitor their CCTV system remotely.

NVR Features

• 4 IP camera channels
• Supports cameras up to 8MP / 4K
• 4 built-in PoE ports
• IEEE 802.3af/at PoE
• Up to 50W total PoE budget
• 4K HDMI output
• H.265+ / H.265 / H.264+ / H.264
• Up to 40Mbps incoming bandwidth
• Up to 80Mbps outgoing bandwidth
• 4-channel synchronous playback
• 1 × SATA HDD bay
• Supports HDDs up to 8TB
• ONVIF compatibility
• HiLookVision / Hik-Connect / iVMS-4200 remote viewing
• 2 × USB 2.0
• 10/100Mbps network interface
• 3-year warranty

Kit Specifications

What's Included

• 2 × HiLook IPC-T363H-MU 6MP Smart Hybrid Light turret cameras
• 2 × HiLook IPC-T269H-MU/SL 6MP Active Deterrence turret cameras
• 1 × HiLook NVR-104MH-C/4P 4-channel PoE NVR
• Standard camera mounting accessories as supplied
• NVR power supply and standard accessories

Hard drive is not included unless an HDD option is selected separately.

Ideal for Home & Business Security

This HiLook 6MP CCTV system is suitable for a wide range of residential and commercial applications, including:

• Homes and residential properties
• Driveways and entrances
• Front and rear yards
• Gates and pathways
• Retail stores
• Offices
• Workshops
• Warehouses
• Small businesses
• Commercial properties
• Outdoor areas requiring additional deterrence

Important Information

The included NVR provides 4 camera channels, matching the four cameras supplied with this CCTV kit.

Both the IPC-T363H-MU and IPC-T269H-MU/SL support IEEE 802.3af PoE, while the NVR supports IEEE 802.3af/at with a 50W total PoE budget.

An HDD is required for NVR video recording and is not included as standard. microSD cards are also not included unless separately specified.

Active deterrence features such as the warning strobe and audible alarm should be configured appropriately for the installation environment and applicable local requirements.
