Dahua 8 Camera CCTV Kit | 6× 3867 + 2× 3849 TiOC 3.0 | 8CH AI PoE NVR

Upgrade your property surveillance with this Dahua 8 Camera CCTV Kit, combining six 8MP WizSense cameras with two 8MP TiOC 3.0 active deterrence cameras and an 8-channel AI PoE NVR.

The kit includes 6 × Dahua DH-IPC-HDW3867EM-S-IL-ANZ 8MP WizSense Dual Light turret cameras and 2 × Dahua DH-IPC-HDW3849H-AS-PV-ANZ-S2 8MP TiOC 3.0 active deterrence turret cameras.

The 3867 cameras provide 4K surveillance with Smart Dual Light, human and vehicle classification, built-in microphones and intelligent video features. The two 3849 TiOC 3.0 cameras add active deterrence with red/blue strobe lighting, a built-in speaker and two-way audio.

All eight cameras connect directly to the Dahua DHI-NVR4108HS-8P-AI/ANZ 8-channel AI PoE NVR, providing an integrated recording and management solution for homes, businesses, warehouses, retail premises and other properties.

What's Included

• 6 × Dahua DH-IPC-HDW3867EM-S-IL-ANZ
  • 8MP 4K WizSense Dual Light Turret Cameras
• 2 × Dahua DH-IPC-HDW3849H-AS-PV-ANZ-S2
  • 8MP 4K TiOC 3.0 Active Deterrence Turret Cameras
• 1 × Dahua DHI-NVR4108HS-8P-AI/ANZ
  • 8-Channel AI WizSense NVR with 8 PoE+ Ports

6 × Dahua DH-IPC-HDW3867EM-S-IL-ANZ – 8MP WizSense Cameras

The six 3867 cameras provide 8MP 4K surveillance with Dahua WizSense intelligent detection and Smart Dual Light technology. They use infrared and warm illumination, with each providing up to 30m illumination.

Key Features

• 8MP 4K resolution
• 3840 × 2160 at up to 25/30 fps
• 1/2.7-inch CMOS sensor
• Smart Dual Light with IR and warm light
• Up to 30m IR illumination
• Up to 30m warm light illumination
• SMD 4.0 human and vehicle classification
• AI SSA
• AcuPick
• Smart Search
• Built-in microphone
• 120dB WDR
• 2.8mm or 3.6mm fixed-focal lens options
• H.265/H.264 compression support
• MicroSD support up to 512GB
• 12VDC or PoE 802.3af
• IP67 metal housing
• Operating temperature from –40°C to +60°C

3867 Lens Options

2 × Dahua DH-IPC-HDW3849H-AS-PV-ANZ-S2 – 8MP TiOC 3.0 Cameras

The two 3849 cameras are designed for locations where active deterrence and two-way communication are required. Dahua TiOC 3.0 combines surveillance, deterrence lighting and audio functionality in one camera.

Key Features

• 8MP 4K resolution
• 3840 × 2160 at up to 25/30 fps
• 1/2.7-inch CMOS sensor
• F1.0 fixed-focal lens
• 2.8mm or 3.6mm lens options
• Smart Dual Light with IR and warm light
• Up to 30m IR illumination
• Up to 30m warm light illumination
• TiOC 3.0 active deterrence
• Red/blue strobe light
• Built-in speaker
• Two-way audio
• Built-in microphone
• SMD 4.0 human and vehicle classification
• Intrusion and tripwire detection
• AcuPick
• AI SSA
• Smart Search
• 120dB WDR
• MicroSD support up to 256GB
• 1-channel alarm input/output
• 12VDC or PoE
• IP67 metal housing
• Operating temperature from –40°C to +60°C

3849 Lens Options

Dahua DHI-NVR4108HS-8P-AI/ANZ – 8-Channel AI PoE NVR

The included 8-channel Dahua NVR provides recording and management for all eight cameras. It features 8 built-in PoE ports, allowing compatible cameras to be connected directly to the recorder.

Key Features

• 8-channel WizSense AI NVR
• 8 built-in PoE ports
• IEEE 802.3af/at PoE support
• Supports IP cameras up to 16MP
• Up to 256Mbps incoming/recording/outgoing bandwidth with AI disabled
• Up to 180Mbps bandwidth with AI enabled
• Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG
• Up to 4 × 8MP@30fps decoding with AI disabled
• 1-channel face detection/recognition
• 2-channel perimeter protection
• 4-channel SMD Plus
• Supports camera-side AI functions including face detection/recognition, perimeter protection, SMD, ANPR, people counting, stereo analysis and heat map
• Up to 10 face databases
• Supports up to 20,000 face images
• 1 × SATA interface supporting up to 20TB
• 8-channel simultaneous playback
• HDMI and VGA outputs
• Gigabit Ethernet
• ONVIF T/S/G support
• iOS and Android support
• 78W total PoE budget
• Up to 25.5W per PoE port

Kit Configuration

Why This Configuration?

This kit combines standard 8MP WizSense cameras with two TiOC 3.0 cameras. The six 3867 cameras can be used for general surveillance areas, while the two 3849 cameras can be positioned at areas where active deterrence, strobe lighting and two-way audio are useful.

The 8-channel PoE NVR provides eight PoE camera connections, matching the eight cameras included in the kit.

Ideal Applications

Suitable for:

• Homes and residential properties
• Driveways and entrances
• Retail stores
• Offices
• Warehouses
• Commercial properties
• Workshops
• Building entrances
• Car parks
• Property perimeters
• Commercial yards
• General outdoor surveillance

Important Compatibility Note

The kit contains 8 cameras total: 6 × DH-IPC-HDW3867EM-S-IL-ANZ and 2 × DH-IPC-HDW3849H-AS-PV-ANZ-S2. The included DHI-NVR4108HS-8P-AI/ANZ is an 8-channel NVR with 8 PoE ports, matching the eight-camera configuration.


⚠️ Hard drive sold separately — this kit does not include a hard drive, so you can choose the storage capacity that suits your recording needs (the NVR supports up to 16TB via its SATA interface).
