The Dahua 8 Camera CCTV Kit combines six 6MP WizSense Dual Light turret cameras with two advanced 8MP TiOC PRO WizColor active deterrence cameras and an 8-channel AI PoE NVR.

The six Dahua DH-IPC-HDW3667EM-S-IL-ANZ cameras provide 6MP surveillance, Smart Dual Light illumination, SMD 4.0 human and vehicle classification, AcuPick and intelligent perimeter protection. Their built-in microphones provide one-way audio recording, while the IP67 metal housing makes them suitable for indoor and outdoor installations.

The two Dahua DH-IPC-HDW3849H-AS-PV-PRO-ANZ cameras provide 8MP 4K surveillance with a larger 1/1.8" CMOS sensor, F1.0 aperture, WizColor PRO technology and Smart Dual Light illumination. They also feature TiOC PRO active deterrence with red and blue sound and light alarms, built-in speaker, dual microphones and two-way audio.

All eight cameras connect to the included Dahua DHI-NVR4108HS-8P-AI/ANZ 8-channel WizSense AI NVR, which has eight built-in PoE ports for direct camera connection. The NVR supports cameras up to 16MP, AI functions and up to 20TB HDD storage.

What's Included

• 6 × Dahua DH-IPC-HDW3667EM-S-IL-ANZ
  • 6MP WizSense Dual Light Turret CCTV Camera
• 2 × Dahua DH-IPC-HDW3849H-AS-PV-PRO-ANZ
  • 8MP 4K TiOC PRO WizColor Active Deterrence Turret Camera
• 1 × Dahua DHI-NVR4108HS-8P-AI/ANZ
  • 8-Channel WizSense AI NVR with 8 PoE+ Ports

6 × Dahua DH-IPC-HDW3667EM-S-IL-ANZ – 6MP WizSense Dual Light Cameras

The six 3667 cameras are designed for general surveillance applications where high-resolution imaging, intelligent detection and flexible night-time illumination are required.

Key Features

• 6MP high-resolution imaging
• 3288 × 1850 at up to 25/30 fps
• 1/2.7-inch CMOS sensor
• 2.8mm fixed-focal F1.4 lens
• Smart Dual Light technology
• Up to 30m IR illumination
• Up to 30m warm-light illumination
• SMD 4.0 human and vehicle classification
• Intrusion and tripwire detection
• AcuPick
• Smart Search
• AI SSA
• Built-in microphone
• One-way audio recording
• 120dB WDR
• MicroSD support up to 512GB
• H.265, H.264, Smart H.265+, Smart H.264+ and AI coding
• 12VDC or PoE 802.3af
• IP67 metal housing
• Operating temperature –40°C to +60°C

3667 Technical Specifications

2 × Dahua DH-IPC-HDW3849H-AS-PV-PRO-ANZ – 8MP TiOC PRO WizColor Cameras

The two 3849 PRO cameras are the advanced active-deterrence cameras in this kit. They combine 4K resolution with a larger 1/1.8" CMOS sensor, F1.0 aperture and WizColor PRO technology for detailed colour imaging in low-light conditions.

Key Features

• 8MP 4K Ultra HD resolution
• 3840 × 2160 resolution
• 1/1.8" CMOS image sensor
• F1.0 fixed-focal lens
• 2.8mm / 3.6mm focal length options
• WizColor PRO technology
• Smart Dual Light
• Up to 30m IR illumination
• Up to 30m warm-light illumination
• TiOC PRO active deterrence
• Red and blue sound and light alarms
• Built-in dual microphones
• Built-in speaker
• Two-way audio
• SMD 4.0 human and vehicle classification
• AcuPick
• AI SSA
• Intrusion and tripwire detection
• Stay and loitering detection
• Full-image face detection
• 120dB WDR
• microSD support up to 512GB
• FTP / SFTP / NAS
• 12VDC / PoE
• IP67 metal housing
• 3-year Australian warranty support

3849 PRO Technical Specifications

The camera's TiOC PRO active deterrence combines red and blue lighting with an audible alarm, while the built-in speaker and dual microphones provide two-way audio communication.

Dahua DHI-NVR4108HS-8P-AI/ANZ – 8-Channel AI PoE NVR

The included Dahua DHI-NVR4108HS-8P-AI/ANZ provides recording, camera management and AI processing for the eight-camera system.

It features 8 integrated PoE ports, allowing the eight cameras to connect directly to the NVR for network connectivity and power. The NVR supports IP cameras up to 16MP and provides 78W of total PoE power.

Key Features

• 8-channel WizSense AI NVR
• 8 built-in PoE ports
• IEEE 802.3af/at
• Supports cameras up to 16MP
• 256Mbps incoming/recording/outgoing bandwidth with AI disabled
• 180Mbps with AI enabled
• Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG
• Up to 4 × 8MP @ 30fps decoding with AI disabled
• 1-channel face detection and recognition
• 2-channel perimeter protection
• 4-channel SMD Plus
• Supports compatible camera AI including ANPR, people counting, stereo analysis and heat map
• Up to 10 face databases
• Up to 20,000 face images
• 1 × SATA HDD interface
• Supports HDD up to 20TB
• HDMI and VGA outputs
• Up to 8-channel simultaneous playback
• Gigabit Ethernet
• ONVIF Profile T, S and G
• iOS / Android mobile access

Kit Configuration

Ideal Applications

This mixed-camera configuration is suitable for:

• Homes and residential properties
• Driveways and entrances
• Retail stores
• Offices
• Warehouses
• Commercial properties
• Workshops
• Building entrances
• Car parks
• Property perimeters
• Commercial yards
• Areas requiring active deterrence

The NVR is specifically suited to home security, small businesses, retail, offices, workshops, warehouses, commercial properties and 8-camera PoE installations.

Why Choose This 8-Camera Dahua Kit?

This configuration provides a combination of general surveillance and active deterrence. The six 3667 cameras can cover standard monitoring areas, while the two 3849 PRO cameras can be positioned at higher-priority locations such as entrances, driveways or property perimeters where 4K WizColor imaging, two-way audio and active deterrence are beneficial.

⚠️ Hard drive sold separately — this kit does not include a hard drive, so you can choose the storage capacity that suits your recording needs (the NVR supports up to 16TB via its SATA interface).
