Dahua 6-Camera CCTV Kit | 5 × 6MP 3667 WizSense + 1 × 8MP 3849 180° Panoramic TiOC Duo + 8CH PoE NVR

Complete Dahua CCTV security system featuring five 6MP WizSense Dual Light turret cameras, one 8MP 180° panoramic TiOC Duo camera and an 8-channel PoE AI NVR. Designed for homes, businesses, warehouses, retail premises and commercial properties requiring detailed surveillance with wide-area panoramic coverage.

What's Included

Key Features

• 6 total cameras for comprehensive property surveillance
• 5 × 6MP WizSense cameras for detailed standard coverage
• 1 × 8MP 180° panoramic camera for wide-area surveillance from a single mounting point
• 180° panoramic coverage from the Dahua 3849 Duo
• SMD 4.0 AI detection with human and vehicle classification
• AcuPick and Smart Search with compatible Dahua NVR systems
• Smart Dual Light for enhanced night-time visibility
• Active deterrence on the 3849 Duo with red/blue warning lights and built-in speaker
• Two-way audio through the 3849 Duo
• Built-in microphones on all cameras
• 120dB WDR on the 3849 Duo and 3667
• PoE connectivity for simplified installation
• IP67 weather protection for outdoor installations
• 8-channel NVR leaves 2 channels available for future expansion

5 × Dahua 6MP WizSense Dual Light Cameras

The DH-IPC-HDW3667EM-S-IL-ANZ cameras provide 6MP surveillance with a 2.8mm F1.4 lens, delivering detailed footage for general monitoring areas such as entrances, side paths, driveways and building exteriors.

Their Smart Dual Light system provides up to 30m IR and 30m warm-light illumination. SMD 4.0 helps distinguish humans and vehicles from other motion, while AcuPick and Smart Search provide additional tools for locating relevant events.

Each camera includes a built-in microphone for one-way audio recording. These cameras do not include a built-in speaker or two-way audio.

1 × Dahua 8MP 180° Panoramic TiOC Duo

The DH-IPC-PDW3849-A180-AS-PV-ANZ is the premium wide-area camera in this kit.

Its dual 1/2.7" CMOS sensors produce an 8MP panoramic image with up to 4096 × 1860 resolution and a 180° horizontal field of view. This makes it particularly useful for locations where a conventional single camera would provide limited coverage.

It supports:

• 180° panoramic viewing
• 8MP resolution
• Dual image sensors
• 2.8mm fixed lenses
• 120dB WDR
• Smart Dual Light
• Up to 25m IR illumination
• Up to 20m warm-light illumination
• SMD 4.0
• Human and vehicle classification
• Intrusion and tripwire detection
• Stay and loitering detection
• EPTZ target tracking
• Built-in dual microphones
• Built-in speaker
• Two-way audio
• Red/blue sound-and-light active deterrence
• MicroSD storage up to 512GB
• IP67 protection

180° Panoramic Coverage

The 3849 Duo is ideal for monitoring wide entrances, driveways, car parks, shopfronts, building perimeters and open areas.

Its 180° panoramic view can cover a much wider area than a conventional fixed-lens camera from a single mounting location, potentially reducing the need for additional cameras in suitable installations.

Active Deterrence

Unlike the 3667 cameras in this kit, the 3849 Duo includes a built-in speaker and red/blue warning lights.

When configured with supported detection and alarm rules, the camera can provide audible and visual deterrence. Its built-in microphones also enable two-way audio communication through compatible Dahua software and systems.

8-Channel PoE AI NVR

The included Dahua DHI-NVR4108HS-8P-AI/ANZ provides eight IP camera channels and eight integrated PoE ports.

With six cameras connected, two NVR channels remain available, allowing the system to be expanded later without replacing the recorder.

The NVR supports:

• 8 IP camera channels
• Up to 16MP camera resolution
• 8 integrated PoE ports
• IEEE 802.3af/at
• 78W total PoE budget
• Up to 256Mbps incoming bandwidth with AI disabled
• Up to 180Mbps with AI enabled
• Smart H.265+
• H.265
• Smart H.264+
• H.264
• Face detection and recognition
• Perimeter protection
• SMD Plus
• Camera-side AI functions
• HDMI and VGA video output
• SATA HDD support up to 20TB
• Dahua mobile viewing via iOS and Android

Recommended Camera Placement

A typical installation could use the cameras as follows:

Actual camera positioning should be determined according to the property's layout, required identification distances and lighting conditions.

Technical Specifications — 3667 Cameras

Technical Specifications — 3849 Duo

Technical Specifications — 8CH NVR

Important Notes

• HDD/storage is not included unless specifically stated in the kit.
• Network cabling and installation are not included.
