Complete Dahua 8MP panoramic CCTV security system featuring six 180° TiOC Duo cameras and an 8-channel PoE AI NVR. Designed for homes, businesses, retail stores, warehouses, car parks and commercial properties requiring wide-area surveillance, intelligent detection and active deterrence.

What's Included

Key Features

• 6 × 8MP panoramic cameras for high-resolution wide-area surveillance
• 180° panoramic coverage from each camera
• Dual 1/2.7" CMOS sensors for wide panoramic imaging
• Up to 4096 × 1860 resolution
• 2.8mm fixed-focal lenses
• Smart Dual Light with up to 25m IR and 20m warm-light illumination
• 120dB WDR for challenging lighting conditions
• SMD 4.0 intelligent human and vehicle detection
• Intrusion and tripwire detection with human/vehicle classification
• Stay and loitering detection
• EPTZ target tracking for digitally enlarging and tracking alarm targets
• Built-in dual microphones and speaker
• Two-way audio
• Red/blue sound-and-light active deterrence
• MicroSD support up to 512GB per camera
• PoE connectivity for simplified installation
• IP67 weather-resistant metal housing
• 8-channel AI NVR with 2 spare channels for future expansion

Dahua 8MP 180° Panoramic TiOC Duo Camera

The Dahua DH-IPC-PDW3849-A180-AS-PV-ANZ is the premium camera included in this kit, combining two image sensors to create a 180° panoramic surveillance view.

Instead of using a conventional narrow field of view, the camera provides broad coverage from a single mounting position. This makes it particularly useful for driveways, entrances, shopfronts, car parks, building perimeters and large open areas.

With 8MP resolution, 120dB WDR, Smart Dual Light, SMD 4.0, EPTZ and TiOC active deterrence, the camera combines wide-area coverage with intelligent security features.

180° Panoramic Surveillance

Each camera uses dual 1/2.7" CMOS sensors and produces a panoramic image with up to 4096 × 1860 resolution.

The 180° horizontal field of view allows one camera to monitor a significantly wider area than a conventional fixed camera.

This can be particularly useful where you need to monitor:

• Wide driveways
• Building entrances
• Shopfronts
• Car parks
• Warehouses
• Building perimeters
• Large outdoor areas

Smart Dual Light Night Vision

The camera combines infrared and warm-light illumination to provide flexible night-time surveillance.

• IR illumination: Up to 25m
• Warm light: Up to 20m
• Illuminator control: Auto / Manual

The warm light can help maintain colour information in suitable low-light conditions while also providing a visible deterrent.

Intelligent AI Detection

The camera supports SMD 4.0 and intelligent perimeter protection, helping identify relevant human and vehicle activity.

Supported functions include:

• SMD 4.0
• Human and vehicle classification
• Intrusion detection
• Tripwire detection
• Stay detection
• Loitering detection
• EPTZ target tracking
• Smart Search with compatible Dahua NVR
• Quick Pick with compatible AI NVR

EPTZ Target Tracking

The integrated EPTZ functionality allows the system to digitally enlarge and track targets associated with intelligent alarm events.

This is useful when monitoring a wide panoramic scene and needing to examine a particular person or vehicle without physically moving the camera.

TiOC Active Deterrence

Each camera includes active deterrence features, combining a built-in speaker with red/blue warning lights.

When configured with compatible detection and alarm rules, the camera can provide an audible and visual warning when suspicious activity is detected.

The camera also includes dual microphones and a speaker for two-way audio communication through compatible Dahua software and systems.

8-Channel PoE AI NVR

The included Dahua DHI-NVR4108HS-8P-AI/ANZ provides recording, management and AI functionality for the six cameras.

With 8 available IP channels, this kit uses six channels and leaves 2 channels available for future expansion.

NVR Features

• 8 IP camera channels
• Supports cameras up to 16MP
• 8 integrated PoE ports
• IEEE 802.3af/at PoE support
• 78W total PoE budget
• Up to 256Mbps incoming bandwidth with AI disabled
• Up to 180Mbps with AI enabled
• Smart H.265+
• H.265
• Smart H.264+
• H.264
• Face detection and recognition
• Perimeter protection
• SMD Plus
• Camera-side AI functions
• HDMI and VGA outputs
• 2 × USB 2.0
• 1 × SATA HDD bay
• Supports HDDs up to 20TB
• Dahua DMSS mobile app support

Technical Specifications — 3849 Duo Camera

Technical Specifications — 8CH NVR

Ideal Applications

This kit is particularly suited to:

• Residential properties
• Large homes and driveways
• Retail stores
• Warehouses
• Offices
• Workshops
• Commercial buildings
• Car parks
• Building perimeters
• Wide entrances and open areas

Important Notes

• Hard drive/storage is not included unless specifically stated in the kit.
• Network cabling and professional installation are not included.
