Dahua 6-Camera 6MP 3649 TiOC CCTV Kit | 6 × WizSense Active Deterrence + 8CH PoE NVR

Complete Dahua TiOC CCTV security system featuring six 6MP WizSense Smart Dual Light cameras and an 8-channel PoE AI NVR. Designed for homes, businesses, retail stores, warehouses and commercial properties requiring high-resolution surveillance, intelligent human and vehicle detection, active deterrence and reliable night-time monitoring.

What's Included

Key Features

• 6 × 6MP Dahua TiOC WizSense cameras
• 6MP resolution up to 3072 × 2048
• Smart Dual Illumination with up to 30m IR and 30m warm light
• TiOC active deterrence with red/blue warning lights and built-in speaker
• Two-way audio with built-in microphone and speaker
• SMD 4.0 human and vehicle detection
• AcuPick intelligent target searching
• AI SSA for automatic image parameter adjustment
• Intrusion and tripwire detection
• 120dB WDR
• H.265 / Smart H.265+ / AI H.265 compression
• MicroSD support up to 256GB per camera
• PoE connectivity
• IP67 weather-resistant metal housing
• 8-channel PoE NVR, leaving 2 channels available for expansion
• Dahua DMSS mobile viewing for iOS and Android

Dahua 6MP TiOC WizSense Cameras

The DH-IPC-HDW3649H-AS-PV-ANZ-S2 combines 6MP high-resolution imaging with Dahua's TiOC active deterrence technology. The 1/2.7" CMOS sensor provides up to 3072 × 2048 resolution at 25/30fps, while the F1.0 fixed-focal lens is designed to deliver strong low-light performance.

The cameras feature both IR and warm-light illumination, with each providing up to 30 metres of illumination. The Smart Dual Light system allows the cameras to adapt their illumination according to the surveillance environment.

TiOC Active Deterrence

Each camera includes integrated active deterrence with:

• Red and blue warning lights
• Built-in speaker
• Built-in microphone
• Two-way talk
• Sound and light alarm
• One-tap arming/disarming

This allows the cameras to provide both surveillance and an active response when supported detection rules are triggered.

Intelligent Human & Vehicle Detection

SMD 4.0 helps distinguish people and vehicles from other motion, helping reduce irrelevant security events.

The cameras also support:

• Intrusion detection
• Tripwire detection
• Human/vehicle classification
• AcuPick
• Smart Search
• AI SSA

AcuPick uses deep-learning algorithms with compatible back-end devices to help locate people and vehicles in live or recorded footage.

Smart Dual Light Night Vision

Each camera provides:

• IR illumination: up to 30m
• Warm light: up to 30m
• Auto or manual illuminator control

This provides flexible night-time monitoring while allowing warm light to be used where colour surveillance and visible deterrence are beneficial.

120dB WDR & Image Enhancement

The cameras include 120dB WDR, helping balance bright and dark areas within the same scene.

Additional image-processing features include:

• 3D noise reduction
• BLC
• HLC
• Scene Self-Adaptation
• Defog
• Smart Illumination
• ROI
• Privacy masking
• Image rotation

8-Channel PoE AI NVR

The included Dahua DHI-NVR4108HS-8P-AI/ANZ provides eight IP camera channels and integrated PoE connectivity.

With six cameras installed, the system has two spare channels, allowing additional compatible cameras to be added later.

The NVR provides:

• 8 IP camera channels
• Support for cameras up to 16MP
• 8 × PoE ports
• IEEE 802.3af/at
• 78W total PoE budget
• Up to 256Mbps incoming bandwidth with AI disabled
• Smart H.265+
• H.265
• Smart H.264+
• H.264
• Face detection/recognition
• Perimeter protection
• SMD Plus
• Camera-side AI functions
• HDMI and VGA outputs
• 1 × SATA HDD bay
• HDD support up to 20TB
• Dahua DMSS mobile app

Technical Specifications — 3649 TiOC Camera

These specifications are based on Dahua's current Australian product information for the ANZ-S2 model.

Ideal Applications

This kit is well suited to:

• Homes and residential properties
• Driveways and entrances
• Retail stores
• Warehouses
• Offices
• Workshops
• Commercial buildings
• Small businesses
• Building perimeters
• Car parks and outdoor areas

Important Notes

• Hard drive/storage is not included unless specifically stated in the kit.
• Network cabling and installation are not included.
