Description
Description
HiLook 7-Camera CCTV Kit with Active Deterrence
Secure your home or business with this HiLook 7-camera CCTV security system, combining five HiLook IPC-T363H-MU cameras with two HiLook IPC-T269H-MU/SL Active Deterrence cameras and an 8-channel network video recorder (NVR).
This mixed-camera configuration provides a surveillance solution with standard cameras for general monitoring and two Active Deterrence cameras designed to provide additional visual and audible warnings when supported event conditions are met.
Key Features
- 7-camera surveillance system featuring five IPC-T363H-MU cameras and two IPC-T269H-MU/SL Active Deterrence cameras.
- 8-channel NVR for centralised recording and management of compatible IP cameras.
- Active Deterrence technology on the two IPC-T269H-MU/SL cameras, featuring a red and blue warning strobe and audible alarm.
- Smart Dual-Light illumination on the IPC-T269H-MU/SL cameras, combining infrared and white-light illumination.
- Human and vehicle classification on the IPC-T269H-MU/SL cameras.
- Built-in microphone and speaker on the IPC-T269H-MU/SL cameras, supporting two-way audio.
- Expandable channel capacity: one NVR channel remains available for a compatible additional IP camera, subject to compatibility and available PoE power budget.
- 3-year warranty for the NVR and IPC-T269H-MU/SL cameras, subject to the applicable product warranty terms.
Camera Configuration
| Component | Quantity | Model |
|---|---|---|
| Standard turret cameras | 5 | HiLook IPC-T363H-MU |
| Active Deterrence turret cameras | 2 | HiLook IPC-T269H-MU/SL |
| Network video recorder | 1 | HiLook 8-channel NVR |
HiLook IPC-T363H-MU Cameras – 5 Units
The five HiLook IPC-T363H-MU cameras form the main surveillance coverage for this system. Their exact resolution, lens options, night illumination range, AI features and other technical specifications should be confirmed against the supplied model’s datasheet before publication.
HiLook IPC-T269H-MU/SL Active Deterrence Cameras – 2 Units
The IPC-T269H-MU/SL cameras provide additional deterrence features for selected monitoring areas.
Key Features
- 6MP resolution: 3200 × 1800 pixels.
- Smart Dual-Light: infrared and white-light illumination.
- Night illumination: up to 30 metres using IR or white light.
- Human and vehicle classification using deep-learning technology.
- Active Deterrence: red and blue warning strobe with an audible alarm.
- Built-in microphone and 95dB speaker for audio functions and two-way communication.
- 120dB True WDR to help manage scenes with contrasting bright and dark areas.
- Local storage support: microSD, microSDHC and microSDXC cards up to 256GB, plus NAS support.
- PoE connectivity: IEEE 802.3af, Class 3.
- Outdoor protection: IP67-rated metal housing.
IPC-T269H-MU/SL Technical Specifications
| Specification | Details |
|---|---|
| Model | HiLook IPC-T269H-MU/SL |
| Camera Type | Fixed turret network camera |
| Resolution | 6MP – 3200 × 1800 |
| Image Sensor | 1/2.4-inch Progressive Scan CMOS |
| Lens Options | 2.8mm, 4mm or 6mm fixed lens |
| Aperture | F1.6 |
| Wide Dynamic Range | 120dB True WDR |
| Illumination | Smart Dual-Light – IR and white light |
| Illumination Range | Up to 30m |
| AI Detection | Human and vehicle classification |
| Active Deterrence | Red and blue strobe with audible alarm |
| Audio | Built-in microphone and 95dB speaker |
| Two-Way Audio | Supported |
| Local Storage | microSD/SDHC/SDXC up to 256GB; NAS |
| Network | RJ45 10/100Mbps |
| Power | 12V DC or PoE |
| PoE Standard | IEEE 802.3af, Class 3 |
| Compatibility | ONVIF Profiles S, G and T; Hik-Connect |
| Weatherproof Rating | IP67 |
| Operating Temperature | -30°C to 60°C |
| Housing | Metal |
| Dimensions | Ø138.3 × 112.1mm |
| Weight | Approx. 820g |
HiLook 8-Channel Network Video Recorder
The included 8-channel NVR records and manages compatible network cameras from a central device. With seven cameras in the proposed configuration, one channel remains available for a compatible additional camera.
NVR model and exact specifications should be confirmed before publishing, as the configuration provided specifies an 8-channel NVR but does not identify its exact model.
What’s Included
- 5 × HiLook IPC-T363H-MU turret cameras
- 2 × HiLook IPC-T269H-MU/SL Active Deterrence cameras
- 1 × 8-channel network video recorder
Hard drive: Not specified as included. Confirm the selected NVR configuration and storage requirements before purchase.
Suitable Applications
This CCTV kit may suit:
- Homes and residential properties
- Small businesses and retail stores
- Offices and commercial premises
- Workshops and warehouses
- Driveways, entrances and selected perimeter areas
Choose camera placement according to the areas requiring coverage, lighting conditions and the features needed at each location.
Warranty
3 Years Warranty.
