Description
Description
Hikvision DS-7604NI-M1/4P 4 Channel 4 PoE 8K NVR | 32MP IP Camera Support
The Hikvision DS-7604NI-M1/4P is a compact and powerful 4-channel Network Video Recorder (NVR) designed for modern IP CCTV systems. With 4 built-in PoE ports, support for IP cameras up to 32MP resolution, advanced H.265+ video compression and 8K HDMI output, it provides a reliable surveillance recording solution for homes, offices, retail stores and small commercial installations.
The NVR supports up to 4 IP cameras and can decode up to 4 channels at 8MP, making it well suited to high-resolution Hikvision CCTV cameras. The integrated PoE ports provide both network connectivity and power to compatible cameras, helping simplify installation by using a single Ethernet cable per camera.
With 40 Mbps incoming bandwidth, the DS-7604NI-M1/4P can efficiently handle high-resolution IP video streams. Its 8K HDMI output provides ultra-high-definition display capability when connected to a compatible monitor, while independent HDMI and VGA outputs offer flexible viewing options.
A single SATA interface supports a surveillance HDD of up to 16TB, providing ample storage capacity for recorded CCTV footage. The recorder also supports two-way audio, remote connections, alarm interfaces and a range of network protocols for flexible system integration.
Key Features
-
4-Channel IP NVR — Supports up to 4 network cameras for compact CCTV installations.
-
4 Built-in PoE Ports — Connect and power compatible IP cameras directly through the NVR using Ethernet cables.
-
Up to 32MP Camera Input — Supports high-resolution IP cameras with recording resolutions up to 32MP.
-
8K HDMI Output — Supports HDMI output up to 7680 × 4320 at 30Hz for ultra-high-definition monitoring.
-
4-Channel 8MP Decoding — Supports up to 4 channels at 8MP resolution and 30fps.
-
High Incoming Bandwidth — Up to 40 Mbps incoming bandwidth for reliable high-resolution video recording.
-
H.265+ Compression — Reduces storage and bandwidth requirements while maintaining video quality.
-
Up to 16TB HDD Support — One SATA interface supports a hard drive up to 16TB.
-
Two-Way Audio — Supports one-channel two-way audio through the RCA interface.
-
Alarm I/O — Includes 4 alarm inputs and 1 alarm output for compatible security devices.
-
Remote Connectivity — Supports up to 128 remote connections and a wide range of network protocols.
-
Compact 1U Design — Space-efficient chassis suitable for residential and small commercial CCTV systems.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Hikvision DS-7604NI-M1/4P |
| NVR Type | 4-Channel 1U Network Video Recorder |
| IP Camera Inputs | 4 Channels |
| Maximum Camera Resolution | Up to 32MP |
| Incoming Bandwidth | 40 Mbps |
| Outgoing Bandwidth | 80 Mbps |
| Decoding Capacity | 4CH @ 8MP / 8CH @ 4MP / 16CH @ 1080p at 30fps |
| Synchronous Playback | 4 Channels |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| HDMI Output | Up to 8K (7680 × 4320) @ 30Hz |
| VGA Output | Up to 1920 × 1080 @ 60Hz |
| Video Output | HDMI / VGA independent output |
| Audio Output | 1CH RCA |
| Two-Way Audio | 1CH RCA |
| PoE Ports | 4 × RJ45 |
| PoE Standard | IEEE 802.3af / 802.3at |
| PoE Budget | Up to 60W |
| Network Interface | 1 × RJ45 10/100/1000 Mbps |
| Storage | 1 × SATA |
| Maximum HDD Capacity | Up to 16TB |
| Alarm Input / Output | 4 / 1 |
| USB Ports | 1 × USB 2.0 Front + 1 × USB 2.0 Rear |
| Power Supply | 48VDC, 1.875A |
| Power Consumption | ≤15W without HDD and PoE |
| Operating Temperature | -10°C to +50°C |
| Operating Humidity | 10%–90% |
| Dimensions | 320 × 240 × 48 mm |
| Weight | Approx. 1.2kg without HDD |
Ideal Applications
The Hikvision DS-7604NI-M1/4P is ideal for home CCTV systems, small businesses, offices, retail stores, warehouses, reception areas and small commercial properties. Its built-in PoE ports, high-resolution camera support and 8K display output make it a strong choice for a compact, high-definition Hikvision IP camera system.
